New solutions / Fog 70 Neutra-odori

Fog 70 Neutra-odori

Fog 70 module complete with filtering system and mechanical dispenser.

See catalogue

gallery

Fog module 70bar industrial from 114 and 186 nozzles, 3x400V-50Hz:

- System complete with filtering system and mechanical dispenser

- 950rpm pump unit ideal for working continuously
- Control panel with PLC and touchscreen
- Possibility of remote management

highlights

Technical data

CODE	Model	Pressure	Flow rate	N° of nozzles	Power 3x400V- 50Hz	Weight	Preventive maintenance 750hrs (standard)	Preventive maintenance 1500hrs (optional)

ZX.8211	Fog 70 NEUTRA-ODORI	70bar	8,6l/min	114	1,5Kw	75Kg	ZX.75IBG02	ZX.150IBG02

ZX.8215	Fog 70 NEUTRA-ODORI	70bar	14l/min	186	3Kw	78Kg	ZX.75IBG13	ZX.150IBG13

* The max number of nozzles has been calculated by using a nozzle IT.204C with flow rate 020 (0,075l/min) at 70bar

Technical data

- Frame made of aluminium
- Professional pump, crankshaft, with brass head with 3 ceramic plungers
- Electric motor 940g/min, 3x400V-50Hz, S1
- Unloader valve, in brass
- Pressure gauge with glycerine in AISI 304 stainless steel
- Solenoid valve l.p. water inlet 24V-50Hz
- H.p. solenoid valve 24V-50Hz to discharge line pressure
- H.p. switch for no water supply and pipe breaks
- 3/4” M inlet • Outlet, 1/2” M
- Control panel with: thermal switch, PLC and touchscreen to manage the module
- Dimensions WxLxH: 800 x 560 x 1000mm
