Fog 70 Touch

Fog module 70bar industrial.

Fog module 70bar industrial from 13 to 560 nozzles 3x400V-50Hz:

- highly compact
- accessories can be installed directly on board the machine
- control panel with PLC and touchscreen
- system can be remotely managed (optional)

highlights

Technical data

CODE	Model	Pressure	Flow rate	N° of nozzles	Power 3x400V- 50Hz	Weight	Preventive maintenance 750hrs (standard)	Preventive maintenance 1500hrs (optional)

ZX.F70T01	FOG 70 TOUCH	80bar	1 l/min	13	1,5Kw	58Kg	ZX.75IP01	ZX.150IP01

ZX.F70T02	FOG 70 TOUCH	80bar	2 l/min	27	1,5Kw	58Kg	ZX.75IBG01	ZX.150IBG01

ZX.F70T04	FOG 70 TOUCH	80bar	4 l/min	53	1,5Kw	58Kg	ZX.75IBG10	ZX.150IBG10

ZX.F70T06	FOG 70 TOUCH	80bar	6,5 l/min	87	1,5Kw	58Kg	ZX.75IBG10	ZX.150IBG10

ZX.F70T08	FOG 70 TOUCH	80bar	8 l/min	107	1,5Kw	58Kg	ZX.75IBG10	ZX.150IBG10

ZX.F70T11	FOG 70 TOUCH	70bar	11 l/min	147	1,5Kw	58Kg	ZX.75IBG02	ZX.150IBG02

ZX.F70T13	FOG 70 TOUCH	80bar	13 l/min	173	2,2Kw	61Kg	ZX.75IBG08	ZX.150IBG08

ZX.F70T15	FOG 70 TOUCH	80bar	15 l/min	200	2,2Kw	61Kg	ZX.75IBG11	ZX.150IBG11

ZX.F70T18	FOG 70 TOUCH	80bar	18 l/min	240	3Kw	66Kg	ZX.75IBG04	ZX.150IBG04

ZX.F70T21	FOG 70 TOUCH	80bar	21 l/min	280	3Kw	66Kg	ZX.75IBG13	ZX.150IBG13

ZX.F70T26	FOG 70 TOUCH	80bar	26 l/min	347	4Kw	80Kg	ZX.75IBG06	ZX.150IBG06

ZX.F70T33	FOG 70 TOUCH	70bar	33 l/min	440	6,3Kw	98Kg	ZX.75IBG06	ZX.150IBG06

ZX.F70T42	FOG 70 TOUCH	70bar	42 l/min	560	6,3Kw	98Kg	ZX.75IBG07	ZX.150IBG07

* The max number of nozzles has been calculated by using a nozzle IT.204C with flow rate 020 (0,075l/min) at 70bar

Technical data

- Frame made of painted steel
- Professional pump, crankshaft, with brass head with 3 ceramic plungers
- Electric motor 1450g/min, 3x400V-50Hz, S1
- Unloader valve, in brass
- Pressure gauge with glycerine in AISI 304 stainless steel
- Solenoid valve l.p. water inlet 24V-50Hz
- H.p. solenoid valve 24V-50Hz to discharge line pressure
- H.p. switch for no water supply and pipe breaks
- General thermal switch
- 3/4” M inlet
- Outlet, 1/2” M
- Control panel with: thermal switch, PLC and touchscreen to manage the module
- Dimensions WxLxH: 780 x 450 x 500mm
